Home > Products > Iron Removal Equipment>Metal Detector
Metal Detector
- Product Introduction
- An electromagnetic induction device for detecting iron parts of conveying belt material
- Adapt to Belt Width
- 500~1400mm
- Product Improvement
- Voice and light alarm function
Advantages
Digital phase shifter and detection technology
Stable performance
High detection sensitivity
Strong anti- interference ability
Low cost
Convenient operation and maintenance
Long service life
Work Principle
It uses the changing signal that produced when the metal enter into the sensor electromagnetic field, and through electronic technology to process and drive an actuator (electromagnet, motor switch) in order to remove harmful metals.
Application
Metal Detector is suitable for food processing, plastics recycling, crushing (coal / fossil power plant / mining / cement / mining / mineral processing), glass ceramics, chemical, rubber production, paper, tobacco, wood and paper material processing industry
Technical Parameters
| Model | JTQ-500 | JTQ -650 | JTQ -800 | JTQ -1000 | JTQ -1200 | JTQ -1400 |
| Suitable for Belt Width (mm) | 500 | 650 | 800 | 1000 | 1200 | 1400 |
| Long Shaft with Inner Bore (mm) | 700 | 850 | 950 | 1150 | 1370 | 1590 |
| Short Shaft with Inner Bore (mm) | 330 | 330 | 370 | 410 | 510 | 610 |
| Max. Sensitivity for Normal Ore (mm) | 20 ~25 | 25 ~30 | 25 ~30 | 35 ~40 | 45 ~50 | 55 ~60 |
| Max. Sensitivity for Magnetic Ore (mm) | 30 | 35 | 40 | 50 | 60 | 70 |
