Excellent performance of Xinhai belt feeder and disc feeder

Disc jitter

1.Fastening lining plate or replace it
2.Remove debris and bulk materials
3.Replace bearings
4.Replace the bearing body or the bevel gear of vertical reducer

Uneven discharge

1.The gate knife is loose or scraper support is movable；
The sleeve bottom and the disk surface is not parallel；
Bulk material blocking the discharge port；
4.Materials sticking serious in storage bin

1.Fixing gate and the scraper support
2.Adjust and replace sleeve
3.Remove bulk materials
4.Unclog storage bin

Abnormal noise of reducer device

Damage of bearings
Lack of lubricant inside the reducer
Damage of gear

Replace bearings；
Adding oil；
Replace gear

Heat of case

1.Deterioration of oil；
2.Blockage of riser vent

1.Replace oil；
2.Unclog riser vent

Abnormal noise of couplings and drive shaft jittering

Wear of drive shaft bush；
Dry grinding of couplings；
Damage of support body groove (or vertical reducer) bearing；
Damage of tail shaft bearing of horizontal speed reducer；
Damage of couplings

Replace bush；
Adding oil；
Replace bearings；
Replace bearings；
Replace couplings
